The 14D211K is a metal-oxide varistor (MOV) designed for transient voltage suppression in a wide range of electronic circuits. This robust component provides effective protection against voltage surges caused by lightning strikes, inductive load switching, and electrostatic discharge (ESD). Its primary function is to clamp overvoltage events, diverting excess current away from sensitive components and preventing damage. The 14D211K is a through-hole (THT) device, making it easy to install and solder onto printed circuit boards (PCBs). Its radial lead configuration ensures secure mounting and reliable electrical connections. The varistor's compact size allows for integration into space-constrained applications without compromising performance.
With a maximum continuous AC voltage rating of 140VAC and a maximum continuous DC voltage rating of 180VDC, the 14D211K is suitable for use in both AC and DC circuits. Its clamping voltage of 220V provides a defined threshold for voltage suppression, ensuring that sensitive components are protected from overvoltage stress. The 14D211K boasts a surge current capability of 4.5kA, indicating its ability to withstand high-energy transients without degradation. This high surge current rating makes it ideal for applications where exposure to lightning strikes or other high-energy surges is a concern. The varistor's operating temperature range of -40°C to +85°C ensures reliable performance in harsh environmental conditions. This wide temperature range makes it suitable for use in industrial, automotive, and outdoor applications.
Metal-oxide varistors like the 14D211K are non-linear resistors whose resistance varies inversely with the applied voltage. Under normal operating conditions, the varistor exhibits a high resistance, effectively isolating the protected circuit. When a voltage surge occurs, the varistor's resistance rapidly decreases, diverting the surge current to ground and clamping the voltage to a safe level. The 14D211K is commonly used in power supplies, surge protectors, and electronic equipment to protect against voltage transients. It is an essential component for ensuring the reliability and longevity of electronic devices. Its robust construction and high surge current capability make it a dependable choice for demanding applications.
Whether you're designing a power supply for industrial equipment or a surge protector for consumer electronics, the 14D211K provides the protection you need. Its compact size, high surge current rating, and wide operating temperature range make it a versatile solution for a variety of applications. Protect your valuable electronic equipment from voltage surges with the 14D211K varistor. Order yours today and ensure the reliability and longevity of your designs. Don't compromise on protection – choose the 14D211K for peace of mind.
| Product Name | 14D211K Varistor: metal-oxide; THT; 140VAC; 180VDC; 220V; 4.5kA; -40÷85°C |
|---|---|
| SKU | 14D211K |
| Price | £2.25 |
| 14D211K Varistor: metal-oxide; THT; 140VAC; 180VDC; 220V; 4.5kA; -40÷85°C Color | As per image |
| Category | Varistors |
| Brand | Nikko Electronics ltd |
| Product Code | 14D211K |
| Availability | Yes |
Shipping cost is based on order value. Just add products to your cart and use the Shipping Calculator to see the shipping price. We want you to be 100% satisfied with your purchase. Items can be returned or exchanged within 30 days of delivery.
The voltage ratings for the 14D211K THT Metal-Oxide Varistor (MOV) are crucial for proper application. The 140VAC (RMS) and 180VDC represent the maximum continuous operating voltages that the varistor can withstand without significant conduction or degradation. It's essential to select a varistor whose continuous operating voltage is slightly higher than your circuit's nominal supply voltage to prevent premature aging and ensure it only activates during a transient. The 220V refers to the varistor voltage (Vv), typically measured at a specified test current (e.g., 1mA). This is the voltage at which the varistor begins to conduct significantly, clamping the overvoltage. For effective protection, the 220V varistor voltage of the 14D211K THT Metal-Oxide Varistor (MOV) ensures sensitive downstream components are protected from surges exceeding this level, while allowing normal operation at 140VAC or 180VDC.
The 4.5kA surge current rating for the 14D211K THT Metal-Oxide Varistor (MOV) indicates its maximum capability to absorb a single high-current transient event, typically defined by a standard waveform like 8/20µs, without catastrophic failure. This robust rating signifies excellent protection against significant overcurrents, making the 14D211K THT Metal-Oxide Varistor (MOV) suitable for applications exposed to moderate to heavy surge environments. It's particularly effective in scenarios like AC line protection for consumer electronics, industrial control systems, power supplies, and telecommunication equipment where lightning strikes or large inductive load switching can generate substantial surge currents. While 4.5kA offers substantial protection, for extreme exposure or critical infrastructure, a multi-stage protection scheme combining this varistor with other TVS devices might be considered for enhanced reliability and energy dissipation.
The 14D211K THT Metal-Oxide Varistor (MOV) is optimally suited for transient voltage suppression in a broad array of electronic circuits, particularly those operating from 120V to 140VAC or up to 180VDC lines. Its robust 4.5kA surge current capability makes it ideal for protecting power supplies, AC/DC converters, and input stages of sensitive equipment from lightning-induced surges and switching transients. Common applications include household appliances (refrigerators, washing machines), industrial control panels, motor drives, HVAC systems, LED lighting drivers, and IT equipment. The through-hole (THT) design of the 14D211K THT Metal-Oxide Varistor (MOV) also makes it suitable for cost-effective, high-reliability designs where manual or automated through-hole assembly is preferred, ensuring secure mechanical and electrical connections in demanding environments.
For optimal performance and longevity of the 14D211K THT Metal-Oxide Varistor (MOV), proper installation and soldering practices are crucial. As a through-hole (THT) component, ensure the leads are not bent too sharply at the varistor body; maintain a minimum bend radius to prevent stress on the ceramic disc. Mount the 14D211K THT Metal-Oxide Varistor (MOV) as close as possible to the protected circuit's input terminals to minimize lead inductance, which can degrade clamping performance during fast transients. When soldering, use appropriate temperatures and dwell times to prevent thermal stress to the device. Typically, soldering iron temperatures around 350°C for 3-5 seconds or wave soldering at 260°C for 5-10 seconds are acceptable. Avoid excessive mechanical force during assembly and ensure proper lead spacing for secure PCB mounting, contributing to the overall reliability of your surge protection circuit.
The 14D211K THT Metal-Oxide Varistor (MOV) primarily fails in two ways: either short-circuiting or exhibiting increased leakage current. Repeated exposure to surges exceeding its energy rating, or a single massive surge, can cause the varistor to degrade, eventually leading to a short circuit. This failure mode can result in excessive current flow, potentially causing fire or further circuit damage if not properly managed. To mitigate this, it is highly recommended to pair the 14D211K THT Metal-Oxide Varistor (MOV) with a series overcurrent protection device, such as a fuse or circuit breaker. A properly selected fuse will open the circuit if the varistor shorts, isolating the fault and preventing hazards. This combined approach ensures that the 14D211K THT Metal-Oxide Varistor (MOV) effectively protects against transients while maintaining overall system safety and reliability.
The specified operating temperature range of -40°C to 85°C for the 14D211K THT Metal-Oxide Varistor (MOV) indicates its ability to maintain its electrical characteristics and reliability within these thermal limits. Within this range, the varistor voltage (Vv) may exhibit a slight negative temperature coefficient, meaning Vv can decrease marginally at higher temperatures. However, for the 14D211K THT Metal-Oxide Varistor (MOV), this variation is typically minimal and factored into its design, ensuring consistent protection performance. Operating the device outside this range, particularly above 85°C, can accelerate its aging, increase leakage current, and significantly reduce its lifespan and surge handling capability. Conversely, extremely low temperatures below -40°C might affect the material properties, though this is less common for varistors. Adhering to the specified temperature range is crucial for ensuring the long-term reliability and effective transient suppression of the 14D211K THT Metal-Oxide Varistor (MOV).
The lifespan of the 14D211K THT Metal-Oxide Varistor (MOV) is primarily determined by the number and magnitude of surge events it experiences. Each surge event, especially those approaching its maximum 4.5kA rating, causes a slight degradation in the varistor's material, leading to a gradual reduction in its varistor voltage (Vv) and an increase in its leakage current. Over time and with repeated surges, this degradation accumulates. Eventually, the 14D211K THT Metal-Oxide Varistor (MOV) may no longer be able to effectively clamp transients to its specified voltage, or its leakage current may rise significantly, causing excessive heat and potentially leading to a short-circuit failure. While designed for robust protection, it's not an infinite-life device under constant stress. For critical applications, periodic inspection or replacement might be considered, especially in environments prone to frequent or high-energy transients, to ensure the continued optimal performance of the 14D211K THT Metal-Oxide Varistor (MOV).
