74196 INTEGRATED CIRCUIT DIP-14

The 74196 is a high-speed Decade Counter/Divider integrated circuit, commonly used in frequency division, timing circuits, and digital counters. This versatile device is housed in a 14-DIP (Dual In-line Package), making it easy to integrate into breadboards, prototyping boards, and PCB designs. The 74196 functions as a 4-bit BCD decade counter, meaning it counts from 0 to 9 and then resets to 0. It can also be configured as a divide-by-10 counter, generating an output pulse for every 10 input pulses. This feature is particularly useful in frequency synthesizers and timing applications. This IC is part of the popular 7400 series logic family, known for its widespread availability and compatibility with various digital circuits.

The 74196 operates on a standard 5V power supply and offers a high clock frequency, enabling accurate counting and division. It features asynchronous preset inputs, allowing you to load a specific value into the counter. The clear input resets the counter to zero. The 14-DIP package is easy to solder and provides reliable connections. Consider the 74196 for applications such as digital clocks, frequency counters, and timing generators. Its versatility and ease of use make it a valuable component for any digital electronics project.

The 74196 is a reliable and efficient solution for counting and dividing frequencies. Its high speed, versatile functionality, and ease of integration make it an ideal choice for a wide range of digital applications. Its ability to divide frequencies and act as a decade counter makes it a staple in digital electronics. Add the 74196 integrated circuit to your cart today to take advantage of its reliable counting and division capabilities!
