74HCT165 INTEGRATED CIRCUIT DIP-16 PC74HCT165P

The 74HCT165, also known as PC74HCT165P, is a high-speed 8-bit parallel-load shift register integrated circuit, packaged in a 16-pin Dual In-Line Package (DIP-16). This versatile IC is designed for applications requiring parallel-to-serial data conversion, data acquisition, and digital delay lines. Its compatibility with TTL logic levels makes it an excellent choice for systems requiring seamless integration between different logic families. The 74HCT165 operates within a broad voltage range, typically from 2V to 6V, providing flexibility in various power supply configurations. The 74HCT165 features eight parallel inputs (A through H) that can be loaded simultaneously when the parallel load (PL) input is low. Once the data is loaded, it can be shifted out serially through the Q7 output on the rising edge of the clock (CLK) input.

An additional clock inhibit (CLK INH) input allows for controlling the clock signal, enabling or disabling the shifting operation. The 74HCT165 finds extensive use in applications such as keyboard scanning, data multiplexing, and serial communication interfaces. Its high noise immunity and low power consumption make it suitable for both battery-powered and high-density applications. The DIP-16 package facilitates easy insertion and soldering on printed circuit boards (PCBs), making it a favorite among hobbyists, students, and professional engineers alike. When designing with the 74HCT165, it is crucial to adhere to the recommended operating conditions and observe proper decoupling techniques to ensure stable and reliable performance. Utilizing bypass capacitors near the power supply pins can help minimize noise and prevent spurious oscillations.

Furthermore, understanding the timing characteristics of the shift register, such as setup time, hold time, and propagation delay, is essential for achieving accurate and predictable circuit behavior. The 74HCT165 is a robust and dependable component that offers a cost-effective solution for implementing parallel-to-serial data conversion. Whether you are building a complex digital system or a simple data acquisition circuit, the 74HCT165 provides the performance and versatility you need. Enhance your project's capabilities with the 74HCT165. Order yours today and experience the difference in data handling and system integration. Don't miss out on this essential component for your electronics toolkit.

Add the 74HCT165 to your cart today and take your projects to the next level!
