74LS174 TTL LS TTL IC Flip-Flop, 74LS174, D, 20 ns, 40 MHz, 8 mA, DIP16

The 74LS174 is a highly versatile Hex D-type flip-flop integrated circuit that utilizes low-power Schottky (LS) TTL technology to deliver high-speed digital logic performance. This IC contains six individual D-type flip-flops with a common clock and a common master reset, making it an essential component for data storage and synchronization in digital systems. Designed for use in a wide range of applications, from simple hobbyist projects to complex industrial control systems, the 74LS174 is a fundamental building block for any digital designer. Its DIP-16 package ensures compatibility with standard breadboards and printed circuit boards, allowing for easy prototyping and integration. By incorporating the 74LS174 into your circuit, you gain a reliable method for capturing and holding binary data, which is critical for the stable operation of sequential logic circuits.

Technical performance is a key attribute of the 74LS174, featuring a maximum frequency of 40 MHz and a typical propagation delay of just 20 ns. These specifications ensure that the IC can keep up with the demands of modern digital timing requirements, providing fast and accurate data transitions. The "LS" designation indicates that it consumes significantly less power than standard TTL logic while maintaining high-speed operation, making it ideal for energy-efficient designs. Each of the six flip-flops inside the 74LS174 captures information on the data input at the rising edge of the clock pulse. The inclusion of a clear (reset) input allows for the simultaneous clearing of all six flip-flops, which is vital for initializing system states or responding to error conditions. This combination of speed, low power, and functional density makes the 74LS174 a go-to choice for high-performance digital logic.

In practical applications, the 74LS174 is frequently used as a buffer register or a temporary storage unit for digital data. It is particularly effective in designs where multiple bits of data need to be synchronized to a single clock signal, such as in bus-oriented systems or memory interface circuits. The hex configuration allows a single IC to handle six bits of data simultaneously, which saves valuable board space and reduces the overall component count. Because it is part of the widely used 7400 series of logic gates, the 74LS174 is highly compatible with other TTL and CMOS logic families, allowing for seamless integration into existing digital architectures. Whether you are building a simple LED sequencer or a complex data processing unit, the 74LS174 provides the reliable latching functionality required for precise digital control and data management.

The physical design of the 74LS174 in its DIP-16 (Dual In-line Package) format is optimized for both durability and ease of use. The 16-pin layout is clearly defined, with power and ground pins positioned for easy routing on a PCB. The robust plastic encapsulation protects the internal logic gates from environmental factors, ensuring consistent performance over a wide range of operating temperatures. For students and educators, the 74LS174 is an excellent tool for teaching the principles of sequential logic, flip-flops, and timing diagrams. Its predictable behavior and standard logic levels make it easy to analyze with basic test equipment like logic probes and oscilloscopes. In a professional setting, the reliability of the 74LS174 ensures that it can be used in long-term industrial installations where consistent logic performance is a requirement for system uptime.

Choosing the 74LS174 means opting for a time-tested logic solution that has been a standard in the electronics industry for decades. Its low-power Schottky construction provides an excellent balance between speed and power dissipation, which is crucial for preventing heat buildup in densely packed electronic enclosures. The common clock and clear lines simplify the wiring of the circuit, allowing for cleaner designs and easier troubleshooting. Furthermore, the 74LS174's high noise immunity ensures that it can operate reliably even in electrically noisy environments, such as near motors or high-voltage switching supplies. This robustness makes it a preferred choice for automotive, industrial, and consumer electronics where digital signal integrity is paramount. By using this IC, you are ensuring that your digital systems have a solid foundation for data synchronization and state management.

Enhance your digital logic designs with the 74LS174 Hex D-Type Flip-Flop IC and benefit from its proven performance and versatility. Whether you are a professional engineer developing a new control board or a hobbyist exploring the world of TTL logic, this IC provides the six-bit storage capacity you need in a single, compact package. Our 74LS174 integrated circuits are manufactured to meet strict industry standards, ensuring that you receive a component with consistent timing and electrical characteristics. Don't compromise on your digital timing; use the 74LS174 for reliable, high-speed data latching and synchronization. Add this essential logic IC to your cart today and take the next step in creating advanced, high-performance digital systems. With its 40 MHz capability and low power consumption, the 74LS174 is the perfect choice for all your sequential logic and data storage requirements.
