74LS258 CMOS INTEGRATED CIRCUIT DIP-16 SN74LS258BN

The SN74LS258BN is a high-speed quad 2-to-1 data selector/multiplexer integrated circuit, designed for efficient data routing and selection in digital systems. Encased in a 16-pin Dual In-Line Package (DIP), this IC offers a compact and reliable solution for selecting one of two data sources. Its CMOS technology ensures low power consumption and high noise immunity, making it suitable for a wide range of applications. The SN74LS258BN is a versatile component for engineers and hobbyists seeking to streamline data flow in their electronic projects.

This integrated circuit features four independent 2-to-1 multiplexers, each capable of selecting one of two input data lines based on a common select input. The selected data is then routed to the output, providing a simple and effective way to switch between different data sources. The 'LS' designation indicates that it belongs to the Low-power Schottky TTL family, offering a balance between speed and power consumption. The DIP-16 package allows for easy insertion and soldering onto breadboards and PCBs, simplifying prototyping and mass production.

The SN74LS258BN finds applications in data routing, signal selection, and logic function generation. In data routing applications, it can select between different data streams based on a control signal. In signal selection applications, it can choose between different input signals for processing. In logic function generation, it can implement simple logic functions by appropriately connecting the inputs. Its versatile nature makes it suitable for use in computers, communication systems, and industrial control equipment.

Key specifications of the SN74LS258BN include a supply voltage range of 4.75V to 5.25V, a typical propagation delay of 18ns, and a maximum output current of 8mA. These parameters ensure compatibility with a wide range of digital circuits and provide sufficient drive capability for most applications. The operating temperature range typically spans from 0°C to 70°C, making it suitable for use in standard indoor environments. Its robust design and adherence to industry standards guarantee reliable performance and long-term durability.

Whether you are designing a complex digital system or a simple data selection circuit, the SN74LS258BN offers a reliable and cost-effective solution for multiplexing data. Its ease of use, widespread availability, and robust performance make it an indispensable component in any electronics toolkit. Add the SN74LS258BN to your cart today and experience the difference it can make in your next project. Streamline data flow and enhance the functionality of your digital systems with this versatile integrated circuit.
