BP104FS PIN IR photodiode; DIL; SMD; 950nm; 800÷1100nm; 60°; 2nA; 150mW

The BP104FS is a high-sensitivity PIN infrared (IR) photodiode designed for a wide range of light detection applications. This versatile component is available in both DIL (Dual In-Line) and SMD (Surface Mount Device) packages, offering flexibility in mounting options for various circuit board designs. With a peak sensitivity at 950nm and a spectral bandwidth spanning from 800nm to 1100nm, the BP104FS is optimized for detecting near-infrared light sources. Its narrow viewing angle of 60° ensures focused detection, minimizing interference from ambient light. The low dark current of 2nA and power dissipation of 150mW contribute to its high performance and energy efficiency.

This PIN photodiode utilizes a highly sensitive silicon material to convert incoming infrared light into an electrical current. The PIN structure enhances its response time and sensitivity compared to traditional photodiodes. The BP104FS is designed to operate in a reverse bias configuration, where the applied voltage increases the depletion region and improves the collection efficiency of photogenerated carriers. This results in a higher signal-to-noise ratio and more accurate light detection. The device's robust construction ensures reliable performance in various environmental conditions.

The BP104FS finds applications in a diverse range of industries, including remote control systems, light barriers, optical sensors, and medical devices. In remote control systems, it serves as the receiver for infrared signals transmitted from remote controls, enabling wireless control of electronic devices. In light barriers, it detects interruptions in the infrared beam, triggering an alarm or control signal. In optical sensors, it measures the intensity of infrared light, providing feedback for various control systems. In medical devices, it can be used for pulse oximetry and other non-invasive monitoring applications.

The BP104FS is available in both DIL and SMD packages, offering flexibility in mounting options for different circuit board designs. The DIL package is suitable for through-hole mounting, while the SMD package is ideal for surface mount assembly. The SMD package offers a smaller footprint and allows for higher component density on the circuit board. Both packages are designed for easy integration into existing and new circuit designs. The device's compact size and versatile mounting options make it a convenient choice for various applications.

Enhance your light detection capabilities with the BP104FS PIN IR photodiode. Its high sensitivity, narrow viewing angle, and low dark current make it an ideal choice for a wide range of applications. Whether you're designing a remote control system, a light barrier, or an optical sensor, the BP104FS will provide the reliable performance you need. Order yours today and experience the difference in quality and performance!
