DM7438N CMOS INTEGRATED CIRCUIT DIP-14

The DM7438N is a quad 2-input NAND gate with open-collector outputs, fabricated using CMOS technology and housed in a 14-pin Dual In-line Package (DIP-14). This integrated circuit is designed for a wide range of digital logic applications where wired-AND or busing capabilities are required. Its open-collector outputs allow multiple gates to be connected together to perform logic functions not possible with standard totem-pole outputs. The DM7438N offers a versatile and reliable solution for implementing complex logic circuits in various electronic systems.

Each of the four NAND gates within the DM7438N performs the logical NAND operation on its two inputs. The output of the gate is low only when both inputs are high; otherwise, the output is high. The open-collector output configuration means that the output transistor's collector is not internally connected to a voltage source. Instead, an external pull-up resistor is required to provide a high output voltage. This configuration allows for wired-AND connections, where multiple open-collector outputs are connected together, and the resulting output is low if any of the individual outputs are low.

The DM7438N operates within a wide supply voltage range, typically from 2V to 6V, making it compatible with various logic levels. Its CMOS technology ensures low power consumption, making it suitable for battery-powered applications. The DIP-14 package allows for easy installation on printed circuit boards (PCBs) and breadboards. The IC's robust design and internal protection circuitry enhance its reliability and longevity. The DM7438N is a popular choice for implementing logic functions in digital systems.

This integrated circuit is ideal for use in a variety of applications, including logic gates, signal inverters, level shifters, and bus drivers. Its open-collector outputs make it particularly useful in applications where multiple devices need to share a common bus. The DM7438N can be used in computers, industrial control systems, and communication equipment. Its versatility and ease of use make it a valuable component for both hobbyists and professional engineers. The DM7438N offers a reliable and cost-effective solution for implementing digital logic functions.

Enhance your digital logic projects with the DM7438N CMOS Integrated Circuit. Its open-collector outputs and low power consumption make it a versatile and efficient choice for a wide range of applications. Order now and experience the reliability and performance of the DM7438N. Don't miss this opportunity to simplify your logic circuit designs. Add to cart today and start building with confidence. Invest in quality, invest in the DM7438N!
