GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC

Skip to the beginning of the images gallery

GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC

3 Reviews Add Your Review

41 people are viewing this right now

In Stock

SKU

191756421211

£10.45

Safe Checkout, Guaranteed

Details

The GAL16V8D-25LPN is a high-performance Generic Array Logic (GAL) device, offering a flexible and versatile solution for implementing custom logic circuits. Housed in a DIP-20 (Dual In-line Package) format, this integrated circuit provides a programmable alternative to traditional discrete logic gates. Its reprogrammability allows for easy design changes and modifications, saving time and reducing development costs. The GAL16V8D-25LPN features eight output logic macrocells (OLMCs), each of which can be individually configured as an input, output, or bidirectional pin. This flexibility enables the implementation of a wide range of logic functions, including counters, decoders, encoders, and state machines. The device is programmed using a standard logic programmer, allowing designers to easily create and test their custom logic designs.

The 25ns propagation delay ensures high-speed operation, making it suitable for demanding applications. The GAL16V8D-25LPN is designed for low-power operation, reducing heat dissipation and extending battery life. Its low quiescent current makes it ideal for portable and battery-powered devices. The DIP-20 package simplifies the prototyping process, allowing for easy experimentation on breadboards and prototyping boards. Its standard pinout makes it easy to integrate into existing circuits. The GAL16V8D-25LPN is a popular choice for replacing traditional TTL and CMOS logic gates.

Its reprogrammability and flexibility make it a cost-effective solution for a wide range of applications. The device is also ideal for implementing custom logic functions in embedded systems and programmable logic controllers (PLCs). Furthermore, the GAL16V8D-25LPN is a non-volatile device, meaning that the programmed logic configuration is retained even when power is removed. This feature ensures that the device will operate correctly even after a power outage. Consider it's utility in address decoding for memory controllers, showcasing its use in embedded systems. Also, contemplate its application in custom peripheral control logic, highlighting its programmability.

This IC is a powerful alternative to discrete logic. Envision its role in implementing custom state machines for industrial control. Replace older, less flexible logic devices with this programmable IC to simplify designs and reduce component count. It can also be used for security applications where the programmed logic is kept confidential. Design complex systems with ease using the GAL16V8D-25LPN. Upgrade your designs with the GAL16V8D-25LPN Integrated Circuit today and unlock the power of programmable logic.

Order yours now and take the first step toward building more flexible and efficient digital systems.

More Information

More Information
Product Name	GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC
SKU	191756421211
Price	£10.45
GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC Color	As per image
Category	Integrated Circuits
Brand	Nikko Electronics ltd
Product Code	191756421211
Availability	Yes

Reviews 3

Write Your Own Review

Shipping and Returns

Shipping cost is based on order value. Just add products to your cart and use the Shipping Calculator to see the shipping price. We want you to be 100% satisfied with your purchase. Items can be returned or exchanged within 30 days of delivery.

Shipping cost is based on order value. Just add GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC to your cart and use the Shipping Calculator to see the shipping price. We want you to be 100% satisfied with your GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC purchase. Items can be returned or exchanged within 30 days of delivery.

FAQ

FAQs for Products

How does the 25ns propagation delay of the GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC impact its performance in high-speed glue logic applications?
The GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC features a maximum propagation delay (tPD) of 25ns, which is a critical specification for designers managing timing budgets in legacy and industrial systems. While modern FPGAs offer faster speeds, the 25ns rating of this specific GAL device is optimized for reliable asynchronous glue logic, address decoding, and state machine implementation where nanosecond-precision is required but extreme high-frequency operation is not the primary goal. In a typical DIP-20 environment, this timing allows the GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC to interface effectively with standard 8-bit and 16-bit microprocessors without introducing excessive wait states. When calculating your system clock, you must account for this 25ns delay alongside the setup and hold times of peripheral components. The 'D' version of this series provides improved switching characteristics over older 'B' or 'C' variants, ensuring cleaner signal transitions and reduced electromagnetic interference in sensitive circuit layouts, making it a robust choice for replacing aging PAL devices.
Can the GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC be programmed using standard JEDEC files from older PAL16V8 devices?
Yes, the GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC is designed to be functionally compatible and pin-for-pin compatible with traditional bipolar PAL16V8 devices. One of the primary advantages of the GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC is its ability to emulate various PAL architectures, including the 16L8, 16R4, 16R6, and 16R8, through its flexible Output Logic Macrocell (OLMC) configuration. When using a standard logic programmer like the TL866II Plus or an industrial-grade equivalent, you can upload existing JEDEC files originally compiled for PALs. The programming software will map the fuse map to the EECMOS cells of the GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC. This makes the device an ideal drop-in replacement for discontinued one-time-programmable (OTP) components. Because this IC uses Electrically Erasable (E2) technology, it eliminates the risk of wasting hardware during the debugging phase, as any errors in the original JEDEC logic can be corrected and the chip can be reflashed instantly.
What are the specific power consumption advantages of the 'L' designation in the GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC?
The 'L' in the GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC part number signifies a 'Low Power' architecture, which is a significant improvement over standard bipolar logic arrays. In high-density DIP-20 board designs, thermal management is often a concern; the GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC addresses this by utilizing advanced EECMOS technology to reduce both standby and active current consumption. Typically, these low-power variants draw significantly less ICC (Supply Current) than their standard counterparts, resulting in lower operating temperatures and extended component longevity. This is particularly beneficial for industrial control systems that operate in enclosed environments where airflow is limited. By choosing the GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC, engineers can reduce the overall power budget of their logic board, potentially allowing for smaller power regulators or the elimination of heat sinks. Furthermore, the lower power draw translates to reduced power supply noise, which enhances the overall signal integrity of the logic outputs across the 20-pin DIP interface.
How do the Output Logic Macrocells (OLMCs) in the GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC provide design flexibility?
The GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC features eight highly versatile Output Logic Macrocells (OLMCs) that allow each of the output pins to be independently configured by the designer. These macrocells can be set into one of three primary modes: Registered, Complex, or Simple. This flexibility allows the GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC to function as a combinational logic gate, a registered output for synchronous state machines, or even as a bidirectional I/O pin. Because each macrocell can be customized, a single GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC can replace several 74-series discrete logic chips, such as flip-flops, multiplexers, and gates, simultaneously. This integration significantly reduces PCB real estate and simplifies the routing of traces. For experienced designers, the ability to define the polarity of each output (active high or active low) within the OLMC further streamlines the interface logic, making this IC a powerful tool for custom decoder and encoder applications where specific logic levels are required for peripheral activation.
What is the expected endurance and data retention for the GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC compared to OTP devices?
Unlike older One-Time Programmable (OTP) PALs that use fuse-link technology, the GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC is built on Electrically Erasable CMOS (EECMOS) technology. This allows the GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC to support at least 100 erase and write cycles, providing a massive advantage during the prototyping and field-update stages of product development. Designers can iteratively refine their logic circuits without physical hardware swaps. In terms of reliability, the GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC offers exceptional data retention, typically rated for over 20 years. This ensures that once the logic is programmed and deployed in an industrial or automotive environment, the configuration remains stable even under fluctuating temperatures and power cycles. The non-volatile memory cells within the GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC are highly resistant to 'bit-flip' errors, making it a much more reliable long-term solution than older UV-erasable EPROM-based logic devices, which required bulky ceramic packages with windows.
Is the GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC compatible with 3.3V CMOS logic systems?
The GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC is primarily a 5V VCC device, designed for TTL and 5V CMOS logic environments. However, it can often be integrated into mixed-voltage systems with careful consideration. The input thresholds of the GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC are TTL-compatible, meaning a logic 'high' from a 3.3V device (typically >2.4V) will correctly trigger the inputs of the GAL. However, the GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC will output 5V signals, which could potentially damage 3.3V-only inputs on sensitive microcontrollers or FPGAs. To safely use the GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC in such scenarios, level shifters or series current-limiting resistors might be necessary if the receiving device is not 5V tolerant. For legacy maintenance where 5V rails are standard, this IC is a perfect fit. If you are designing a new system with the GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC, ensure your power delivery network provides a stable 5V supply to pin 20 to maintain the specified 25ns timing performance.
What are the key differences between the 'D' and 'B' versions of the GAL16V8 series when selecting the GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC?
When sourcing components, understanding the revision history is vital; the 'D' in GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC represents the most advanced and final architectural revision of the 16V8 family. Compared to the older 'B' or 'C' versions, the 'D' revision utilizes a more refined fabrication process that results in improved switching speeds and lower power consumption at a given frequency. The GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC also features enhanced ESD (Electrostatic Discharge) protection, which is crucial for handling and assembly in modern manufacturing environments. Additionally, the 'D' version was designed to minimize ground bounce and output ringing, which were common issues in earlier high-speed programmable logic devices. By selecting the GAL16V8D-25LPN High-Performance Generic Array Logic (GAL) IC, you are ensuring the highest level of compatibility with modern programming algorithms and the best possible electrical performance within the 16V8 product line. This makes it the preferred choice for both repair of vintage computing equipment and the production of robust industrial controllers.
