HX2272-L4 INTEGRATED CIRCUIT DIP-18

The HX2272-L4 is a remote control decoder IC commonly used in wireless remote control systems. Encased in a DIP-18 (Dual In-line Package) package, this integrated circuit is designed to receive and decode signals transmitted by a corresponding encoder, typically the HX2262. These encoder/decoder pairs are widely used in applications such as garage door openers, car alarms, and other remote control devices. The HX2272-L4 is specifically the latching version (L4), meaning that once a signal is received and decoded, the output remains active until another signal is received to deactivate it. This latching functionality is essential for applications where a momentary button press needs to trigger a sustained action. Key features of the HX2272-L4 include its ability to decode up to 12 bits of address and data information, providing a large number of possible combinations and enhancing security.

The IC operates on a supply voltage typically between 2.4V and 12V, offering flexibility in power supply design. The HX2272-L4 utilizes a CMOS process, resulting in low power consumption, which is crucial for battery-powered remote control applications. The IC's simple interface and minimal external component requirements simplify the design process and reduce the overall system cost. The HX2272-L4 is commonly used in applications such as garage door openers, car alarms, remote-controlled toys, and other wireless remote control systems. Its latching functionality, low power consumption, and simple interface make it an ideal choice for these applications. The IC's robust design and reliable performance ensure long-term stability and accuracy.

Its DIP-18 package allows for easy installation and integration into existing circuits. The HX2272-L4 is rigorously tested to meet industry standards, ensuring its quality and reliability. Its high performance and versatile features make it a cost-effective solution for a wide range of remote control needs. Whether you're designing a garage door opener or a remote-controlled toy, the HX2272-L4 provides the performance and reliability you need. Upgrade your remote control system today with the HX2272-L4 decoder IC and experience the benefits of dependable and efficient performance. Order now and take the first step towards a more robust and reliable remote control design.
