SN74HC164N INTEGRATED CIRCUIT DIP-14

The SN74HC164N is an 8-bit serial-in, parallel-out shift register integrated circuit, a versatile component for data manipulation and storage. Encased in a DIP-14 (Dual In-line Package), it's designed for through-hole mounting on printed circuit boards (PCBs), offering ease of prototyping and assembly. This IC belongs to the 74HC family, known for its high-speed CMOS technology, providing excellent performance with low power consumption. The SN74HC164N features a serial data input (DSA and DSB), a clock input (CLK), and eight parallel outputs (QA through QH). Its robust design ensures reliable performance in various digital systems, making it a popular choice for both hobbyists and professionals.

The SN74HC164N shifts data serially into the register on the positive-going edge of the clock signal. The two serial data inputs (DSA and DSB) are ANDed together internally, providing a single serial input. The eight parallel outputs (QA through QH) provide access to the stored data. The IC operates from a wide voltage range (typically 2V to 6V), making it compatible with a variety of digital logic families. Its low power consumption makes it ideal for battery-powered applications. The DIP-14 package provides easy access to all pins, simplifying circuit design and troubleshooting.

The SN74HC164N is commonly used in applications where serial data needs to be converted to parallel data, such as display drivers, data acquisition systems, and communication interfaces. It can also be used to implement shift registers for data storage and manipulation. The IC's versatility makes it suitable for a wide range of applications, including LED displays, digital clocks, and control systems. The SN74HC164N is a fundamental component in digital electronics, providing a simple and reliable way to implement serial-to-parallel data conversion and shift register functions. Its widespread availability and ease of use make it an essential tool for anyone working with digital circuits.

Engineers and hobbyists alike appreciate the SN74HC164N for its ease of use and comprehensive feature set. The IC's well-documented specifications and readily available application notes simplify the design process. Its robust performance and reliable operation make it a popular choice for both commercial and DIY projects. The SN74HC164N is a cost-effective solution for digital logic applications, offering a high level of performance and integration at a competitive price. Its widespread availability and ease of integration make it an excellent choice for a wide range of applications.

Transform your digital projects with the SN74HC164N Integrated Circuit DIP-14. Experience reliable serial-to-parallel data conversion, simplified circuit design, and versatile data manipulation. Order yours today and take your projects to the next level! Benefit from its high-speed CMOS technology, wide operating voltage range, and easy DIP-14 packaging. Don't miss out on this opportunity to enhance your digital logic circuits. Purchase now and enjoy seamless integration and dependable performance.
