UCC3813N-2 PWM Current-Mode Controller IC DIP-8

Skip to the beginning of the images gallery

UCC3813N-2 PWM Current-Mode Controller IC DIP-8

3 Reviews Add Your Review

34 people are viewing this right now

In Stock

SKU

191680459475

£21.00

Safe Checkout, Guaranteed

Details

The UCC3813N-2 is a high-performance, low-power PWM current-mode controller integrated circuit, designed for a wide range of power supply applications. Housed in an 8-pin DIP package, this IC offers a compact and efficient solution for controlling and regulating power conversion processes. Its primary function is to provide the necessary control signals for external MOSFETs or other switching devices, enabling the creation of stable and regulated output voltages. The UCC3813N-2 operates on the current-mode control principle, which offers inherent advantages such as improved line regulation, load regulation, and dynamic response compared to voltage-mode control. This makes it particularly suitable for applications where tight regulation and fast transient response are critical. Key features of the UCC3813N-2 include a wide input voltage range, precise duty cycle control, and built-in protection features such as over-voltage protection (OVP), under-voltage lockout (UVLO), and over-current protection (OCP).

These protection mechanisms ensure the safe and reliable operation of the power supply, preventing damage to the IC and other components in the circuit. The UCC3813N-2 also incorporates a trimmed oscillator for accurate and stable switching frequency, minimizing electromagnetic interference (EMI) and ensuring consistent performance. The current-mode PWM controller architecture allows for cycle-by-cycle current limiting, providing enhanced protection against overload conditions. This IC is commonly used in various power supply applications, including AC-DC adapters, DC-DC converters, battery chargers, and offline power supplies. Its versatility and robust performance make it a popular choice among power supply designers. The UCC3813N-2's compact size and minimal external component requirements contribute to a smaller overall system footprint, making it ideal for space-constrained applications.

Furthermore, its low startup current and quiescent current contribute to improved energy efficiency, reducing power consumption and heat dissipation. Whether you're designing a new power supply or upgrading an existing one, the UCC3813N-2 offers a reliable and cost-effective solution. Its advanced features and robust protection mechanisms ensure stable and efficient power conversion, making it a valuable component in any power electronics design. Upgrade your power supply design with the UCC3813N-2 and experience enhanced performance and reliability. Order yours today and take your power supply to the next level.

More Information

More Information
Product Name	UCC3813N-2 PWM Current-Mode Controller IC DIP-8
SKU	191680459475
Price	£21.00
UCC3813N-2 PWM Current-Mode Controller IC DIP-8 Color	As per image
Category	Integrated Circuits
Brand	Nikko Electronics ltd
Product Code	191680459475
Availability	Yes

Reviews 3

Write Your Own Review

Shipping and Returns

Shipping cost is based on order value. Just add products to your cart and use the Shipping Calculator to see the shipping price. We want you to be 100% satisfied with your purchase. Items can be returned or exchanged within 30 days of delivery.

Shipping cost is based on order value. Just add UCC3813N-2 PWM Current-Mode Controller IC DIP-8 to your cart and use the Shipping Calculator to see the shipping price. We want you to be 100% satisfied with your UCC3813N-2 PWM Current-Mode Controller IC DIP-8 purchase. Items can be returned or exchanged within 30 days of delivery.

FAQ

FAQs for Products

What are the key advantages of selecting the UCC3813N-2 PWM Current-Mode Controller IC DIP-8 for a power supply design over voltage-mode controllers?
The UCC3813N-2 PWM Current-Mode Controller IC DIP-8 offers significant advantages over traditional voltage-mode control, primarily due to its inherent current-mode operation. This control scheme provides improved line regulation because changes in input voltage are immediately reflected in the current loop, allowing for faster compensation. Furthermore, current-mode control delivers superior load regulation, as the controller can more accurately respond to output current demands. A major benefit is the cycle-by-cycle current limiting, which provides robust overcurrent protection, safeguarding the power stage. It also simplifies loop compensation, reducing the complexity of filter design and often requiring fewer external components to achieve stability, making the UCC3813N-2 an efficient and reliable choice for demanding power supply applications requiring tight regulation and dynamic response.
Which power supply topologies are most compatible with the UCC3813N-2 PWM Current-Mode Controller IC DIP-8, and what is its typical output drive capability for external switching devices?
The UCC3813N-2 PWM Current-Mode Controller IC DIP-8 is versatile and well-suited for a wide array of isolated and non-isolated power supply topologies. Its current-mode control makes it highly effective in applications such as boost, buck, flyback, and forward converters, where precise current regulation and fast transient response are critical. These topologies benefit from the IC's ability to simplify design and enhance performance. Regarding output drive capability, the UCC3813N-2 typically features a robust totem-pole output stage designed to directly drive the gates of external power MOSFETs or IGBTs. While specific current ratings vary by datasheet, it is generally capable of sourcing and sinking sufficient current (e.g., hundreds of milliamps to over an amp) to quickly charge and discharge the gate capacitance of medium to high-power switching devices, ensuring efficient and rapid switching transitions for optimal power conversion.
How does the UCC3813N-2 PWM Current-Mode Controller IC DIP-8 contribute to improved line and load regulation in power conversion applications?
The UCC3813N-2 PWM Current-Mode Controller IC DIP-8 significantly enhances both line and load regulation through its unique control methodology. For line regulation, the current-mode architecture inherently provides feedforward control from the input voltage. Any changes in the input voltage are directly sensed by the current loop, allowing the controller to adjust the pulse width almost instantaneously to maintain a stable output, minimizing output voltage fluctuations due to input variations. Regarding load regulation, the inner current loop ensures that the peak inductor current is tightly controlled on a cycle-by-cycle basis. This precise control over the energy delivered to the output allows the UCC3813N-2 to respond rapidly and accurately to sudden changes in the output load, preventing voltage sags or overshoots. This dual-loop control (inner current, outer voltage) is key to its superior regulatory performance.
What are the operational considerations for the UCC3813N-2 PWM Current-Mode Controller IC DIP-8 regarding its switching frequency and duty cycle control?
When utilizing the UCC3813N-2 PWM Current-Mode Controller IC DIP-8, careful consideration of its switching frequency and duty cycle control is paramount for optimal performance. The switching frequency, typically set by an external resistor and capacitor, dictates the size of magnetic components and capacitors, influencing efficiency and transient response. The UCC3813N-2 usually supports a wide operating frequency range, allowing designers flexibility for various application requirements. Its current-mode control inherently provides excellent duty cycle control, as the pulse width is modulated to maintain a constant peak inductor current. This also offers inherent maximum duty cycle clamping, preventing saturation in certain topologies. Designers must ensure the chosen frequency is within the IC's specified limits and that the external timing components are stable across the desired operating temperature range to maintain consistent switching performance and prevent instability or subharmonic oscillations, especially at duty cycles exceeding 50%.
Does the UCC3813N-2 PWM Current-Mode Controller IC DIP-8 include any built-in protection features, and how do they enhance system reliability?
Yes, the UCC3813N-2 PWM Current-Mode Controller IC DIP-8 is typically equipped with several integrated protection features designed to enhance the overall reliability and robustness of the power supply system. A cornerstone of current-mode control is cycle-by-cycle current limiting, which immediately terminates the PWM pulse if the peak current exceeds a pre-set threshold, preventing damage from overcurrent conditions. The UCC3813N-2 also often includes undervoltage lockout (UVLO), ensuring the IC only operates when the input supply voltage is sufficient, preventing erratic behavior or damage during startup or power-down. Additionally, features like soft-start are common, gradually increasing the output voltage during power-up to prevent inrush current surges. These combined protection mechanisms safeguard the power supply, the load, and the IC itself from various fault conditions, contributing to a highly reliable and long-lasting design.
What are the typical external component requirements for configuring a basic regulated power supply using the UCC3813N-2 PWM Current-Mode Controller IC DIP-8?
To configure a basic regulated power supply using the UCC3813N-2 PWM Current-Mode Controller IC DIP-8, several key external components are typically required. Essential for setting the switching frequency is an RC timing network connected to the oscillator pin. A critical component is the external power MOSFET or other switching device, which the UCC3813N-2 drives directly. Inductors and capacitors are needed for energy storage and filtering in the power conversion stage, their values determined by the chosen topology and desired output characteristics. Feedback resistors form a voltage divider to sense the output voltage and provide feedback to the error amplifier. A current sense resistor is crucial for the current-mode control, providing a signal proportional to the inductor or switch current. Additionally, bypass capacitors for the IC's VCC pin and potentially other minor components for soft-start or protection are often included to ensure stable and reliable operation of the UCC3813N-2.
How does the 8-pin DIP package of the UCC3813N-2 PWM Current-Mode Controller IC DIP-8 impact its thermal performance and suitability for various power levels?
The 8-pin DIP (Dual In-line Package) of the UCC3813N-2 PWM Current-Mode Controller IC DIP-8 offers a balance of ease of handling, prototyping, and moderate thermal performance. While DIP packages are generally not as thermally efficient as surface-mount packages designed for high-power dissipation, the UCC3813N-2 itself is a low-power controller. Its internal power dissipation is primarily due to its quiescent current and the power required to drive the external MOSFET gate. For typical applications controlling power supplies up to several tens or even hundreds of watts, the DIP-8 package provides adequate thermal dissipation without requiring extensive external heatsinking for the IC itself. However, for applications pushing the higher end of its specified operating temperature or where the gate drive current is exceptionally high, designers should consider the ambient temperature, board layout, and potential airflow to ensure the junction temperature of the UCC3813N-2 remains within safe operating limits. Its suitability across various power levels depends more on the external power stage components it controls rather than the IC's own thermal limits.
