Connector: automotive; plug; female; JPT; for cable; PIN: 6; blue
Safe Checkout, Guaranteed
The 1-965640-1 is a robust and reliable automotive connector, meticulously designed for demanding vehicle applications. This female plug, engineered to accommodate cable connections, features the industry-standard JPT (Junior Power Timer) interface. It boasts six pins, providing ample connectivity for various automotive electrical systems. The blue color coding aids in quick identification and error prevention during assembly and maintenance. Specifically designed for automotive use, this connector is built to withstand the harsh conditions found under the hood and throughout the vehicle. This includes resistance to extreme temperatures, vibration, moisture, and corrosive fluids.
The JPT interface is known for its secure and reliable locking mechanism, ensuring a stable connection even in high-vibration environments. The six-pin configuration allows for the transmission of multiple signals or power lines through a single connector, simplifying wiring harnesses and reducing overall system complexity. The female plug design ensures compatibility with corresponding male connectors, creating a secure and watertight seal. The connector body is constructed from high-quality, durable materials that resist wear and tear, ensuring a long service life. The blue color not only aids in identification but also helps prevent accidental misconnections. The 1-965640-1 is commonly used in automotive wiring harnesses, sensor connections, actuator controls, and other critical electrical systems.
Its robust design and reliable performance make it an ideal choice for connecting various components throughout the vehicle. This connector is an essential component for any automotive repair or modification project that requires a secure and dependable electrical connection. Whether you're replacing a damaged connector or building a custom wiring harness, the 1-965640-1 offers the quality and reliability you need. Investing in a high-quality connector like the 1-965640-1 ensures the proper functioning and longevity of your automotive electrical system. Don't compromise on the integrity of your connections – choose a connector that is built to last. This connector is also ideal for use in agricultural vehicles, construction equipment, and other heavy-duty applications where a reliable and durable electrical connection is required.
Upgrade your automotive electrical system with the 1-965640-1 Connector. Experience the peace of mind that comes with knowing your connections are secure and dependable. Order yours today and ensure the reliable operation of your vehicle's electrical systems. Don't wait until a faulty connector causes problems – proactively replace worn or damaged connectors with the high-quality 1-965640-1. Add to cart now and keep your vehicle running smoothly.
| Product Name | 1-965640-1 Connector: automotive; plug; female; JPT; for cable; PIN: 6; blue |
|---|---|
| SKU | 1-965640-1 |
| Price | £3.75 |
| 1-965640-1 Connector: automotive; plug; female; JPT; for cable; PIN: 6; blue Color | As per image |
| Category | Connectors |
| Brand | Nikko Electronics ltd |
| Product Code | 1-965640-1 |
| Availability | Yes |
Shipping cost is based on order value. Just add products to your cart and use the Shipping Calculator to see the shipping price. We want you to be 100% satisfied with your purchase. Items can be returned or exchanged within 30 days of delivery.
The 1-965640-1 JPT 6-Pin Female Automotive Cable Plug, Blue is engineered for superior performance in demanding vehicle environments. It provides robust protection against a wide array of harsh conditions, making it ideal for under-the-hood or chassis applications. This connector is designed to withstand extreme temperature fluctuations, typically ranging from -40°C to +125°C, ensuring reliable operation in both cold starts and high-heat engine compartments. Its construction offers excellent resistance to significant vibration, crucial for maintaining connection integrity over rough terrain and prolonged vehicle operation. Furthermore, the JPT interface is inherently designed for moisture resistance, often incorporating sealing features to protect against water ingress, road spray, and humidity. It also exhibits high resistance to common automotive fluids such as oils, fuels, brake fluids, and coolants, preventing material degradation and ensuring long-term electrical stability for your critical automotive systems.
The 1-965640-1 JPT 6-Pin Female Automotive Cable Plug, Blue is specifically designed to mate with its corresponding JPT (Junior Power Timer) male plug connector. To achieve a secure and reliable connection, users must ensure they are pairing it with a genuine JPT 6-pin male counterpart. Key considerations include verifying the pin count, as JPT connectors are available in various configurations, and ensuring the correct 'keying' to prevent mismating. The JPT system is renowned for its robust primary locking mechanism, which creates an audible click when fully engaged, confirming a proper connection. Additionally, the design often incorporates secondary locking features for the individual terminals, preventing accidental pull-out. Always inspect both the male and female connectors for any damage or debris before mating to ensure optimal electrical contact and mechanical integrity, which is vital for the long-term performance of your automotive wiring harnesses.
The 1-965640-1 JPT 6-Pin Female Automotive Cable Plug, Blue is compatible with specific JPT female terminals, which in turn accommodate a range of wire gauges commonly found in automotive applications. Typically, JPT terminals are available for wire sizes ranging from 0.5mm² to 2.5mm² (approximately 20 AWG to 14 AWG), though specific terminal part numbers will dictate the exact compatible gauge. It is crucial to select the correct JPT female terminal for your chosen wire gauge to ensure optimal electrical and mechanical performance. The recommended crimping process involves using a specialized crimping tool designed for JPT terminals. This tool ensures a gas-tight crimp between the wire conductor and the terminal, as well as a proper insulation crimp, which prevents wire strain and protects against environmental ingress. Correct crimping is paramount for the long-term reliability and safety of the connection within the 1-965640-1 JPT 6-Pin Female Automotive Cable Plug, Blue.
The 1-965640-1 JPT 6-Pin Female Automotive Cable Plug, Blue incorporates a highly effective locking mechanism crucial for maintaining connection stability in dynamic automotive environments. At its core, the JPT system features a robust primary latch that securely engages with the corresponding male connector. This primary lock provides a positive, tactile, and often audible 'click' upon full mating, confirming the connection is established and locked. Beyond this, individual JPT female terminals within the housing are secured by a secondary locking feature, typically a TPA (Terminal Position Assurance) or CPA (Connector Position Assurance) mechanism. This secondary lock prevents the terminals from backing out of the connector housing due to vibration or tension on the cables. This dual-stage locking system ensures the electrical interface remains intact even under severe vibrations, impacts, and constant movement inherent in vehicle operation, making the 1-965640-1 JPT 6-Pin Female Automotive Cable Plug, Blue exceptionally reliable for critical automotive circuits.
The 1-965640-1 JPT 6-Pin Female Automotive Cable Plug, Blue is a versatile component widely used across various automotive electrical systems due to its robust design and reliable JPT interface. Its 6-pin configuration makes it suitable for applications requiring multiple signal or power lines. Common uses include connections for sensors such as oxygen sensors, throttle position sensors, or camshaft position sensors, where multiple signal wires and power/ground are needed. It's also frequently found in lighting systems for headlights, taillights, or interior lighting modules, providing secure power and control connections. Other applications extend to engine management systems, ABS (Anti-lock Braking System) components, HVAC (Heating, Ventilation, and Air Conditioning) controls, and various body electronics. The 1-965640-1 JPT 6-Pin Female Automotive Cable Plug, Blue's ability to withstand harsh conditions makes it an excellent choice for any critical automotive circuit requiring a sealed, durable, multi-pin connection.
The 1-965640-1 JPT 6-Pin Female Automotive Cable Plug, Blue is constructed from high-quality, automotive-grade materials selected for their resilience and performance in challenging environments. The connector housing is typically molded from a robust thermoplastic, such as PBT (Polybutylene Terephthalate) or PA (Polyamide/Nylon), which provides excellent mechanical strength, resistance to high temperatures, and chemical compatibility with common automotive fluids like oils, fuels, and coolants. These materials also offer good dielectric properties, ensuring electrical insulation. The internal terminals, designed for crimping onto cables, are usually made from high-conductivity copper alloy (e.g., brass or phosphor bronze) with a protective plating, often tin or silver, to ensure low contact resistance and corrosion prevention. These material choices collectively ensure the 1-965640-1 JPT 6-Pin Female Automotive Cable Plug, Blue maintains its structural integrity, electrical continuity, and sealing capabilities over the vehicle's lifespan, even under constant exposure to vibration and environmental stressors.
The blue color coding of the 1-965640-1 JPT 6-Pin Female Automotive Cable Plug, Blue serves a critical functional purpose in automotive assembly lines and subsequent vehicle maintenance. In complex wiring harnesses with numerous connectors, color coding is a highly effective method for quick identification and error prevention. The blue color typically indicates a specific circuit, application, or mating configuration, helping technicians rapidly distinguish this 6-pin JPT connector from other similar-looking JPT connectors with different pin counts or for different electrical functions (which might be colored black, grey, natural, etc.). This visual cue significantly reduces the risk of incorrect connections, which could lead to system malfunctions, damage to components, or safety hazards. During maintenance or troubleshooting, the distinctive blue color of the 1-965640-1 JPT 6-Pin Female Automotive Cable Plug, Blue allows for fast and accurate identification of the correct connector, streamlining repair processes and improving overall efficiency and reliability of the vehicle's electrical system.
