HD74LS04P HITACHI INTEGRATED CIRCUIT DIP-14 74LS04

The HD74LS04P, manufactured by Hitachi, is a hex inverter integrated circuit belonging to the 74LS family of logic gates. Encased in a DIP-14 (Dual In-Line Package) format, this IC provides six independent inverters, each performing the logical NOT operation. The 74LS04 is a widely used component in digital electronics due to its simplicity, reliability, and compatibility with various logic families. It's commonly employed in signal inversion, waveform shaping, and simple logic functions. The HD74LS04P is a through-hole component, making it easy to prototype and experiment with on breadboards and perfboards. Its robust design ensures stable performance in a variety of applications.

Each of the six inverters within the HD74LS04P takes a single input signal and produces an inverted output signal. If the input is high (logic 1), the output will be low (logic 0), and vice versa. The 74LS04 operates on a 5V power supply and features a low-power Schottky (LS) technology, which provides a good balance between speed and power consumption. This makes it suitable for applications where both performance and energy efficiency are important. The device has a typical propagation delay of around 10 nanoseconds, allowing it to handle moderately fast signals. The input and output pins are TTL (Transistor-Transistor Logic) compatible, ensuring easy interfacing with other TTL devices.

The HD74LS04P finds applications in a wide range of digital circuits. It is commonly used in signal conditioning to invert signals for proper logic operation. It can also be used to create simple oscillators and clock circuits. In digital logic design, it serves as a basic building block for implementing more complex logic functions. Other applications include buffering signals, driving LEDs, and creating simple timing circuits. The 74LS04's versatility and ease of use make it a staple component in many electronic projects. Its widespread availability and low cost further contribute to its popularity among hobbyists and professionals alike.

Key specifications of the HD74LS04P include a supply voltage of 5V, a low-level output current of 8mA, and a high-level output current of -0.4mA. The device operates over a temperature range of 0°C to 70°C, making it suitable for most indoor environments. The DIP-14 package provides easy access to all six inverters, allowing for flexible circuit design. The 74LS04 is also known for its high noise immunity, which helps to prevent false triggering due to noise or interference. Its robust design and reliable performance make it a trusted component in many electronic systems. The HD74LS04P is a reliable and versatile hex inverter IC.

In conclusion, the HD74LS04P Hitachi integrated circuit, a hex inverter in a DIP-14 package, is an essential component for any digital electronics enthusiast or professional. Its six independent inverters, low-power Schottky technology, and TTL compatibility make it a versatile and reliable choice for a wide range of applications. Whether you're working on signal conditioning, logic design, or simple timing circuits, the 74LS04 provides the functionality and performance you need. Don't settle for less – invest in the HD74LS04P today and experience the difference it can make in your projects. Order now to take advantage of our competitive pricing and fast shipping!
