SN74ACT14DR IC: digital; NOT; Ch: 6; SMD; SO14; IN: with Schmitt trigger; ACT

The SN74ACT14DR is a high-performance hex inverter Schmitt trigger integrated circuit belonging to the 74ACT family. This device features six independent inverters, each capable of accepting a single input and producing an inverted output. Housed in a 14-pin Small Outline Integrated Circuit (SOIC) package, the SN74ACT14DR is designed for Surface Mount Device (SMD) assembly, making it suitable for high-density PCB designs. Its Schmitt trigger inputs provide enhanced noise immunity and signal conditioning, ensuring reliable operation even in noisy environments. The 74ACT14 designation signifies its compatibility with advanced CMOS technology, offering a balance of speed and power consumption.

This hex inverter is particularly useful in applications requiring signal inversion, pulse shaping, and noise reduction. The Schmitt trigger inputs of the SN74ACT14DR introduce hysteresis, which prevents oscillations and spurious switching caused by slow or noisy input signals. This makes it ideal for interfacing with sensors, switches, and other real-world inputs that may exhibit signal imperfections. The device operates over a wide voltage range, typically from 4.5V to 5.5VDC, providing flexibility in various circuit designs. Its high output drive capability allows it to directly drive other logic gates or components without the need for additional buffering.

Key specifications of the SN74ACT14DR include a propagation delay of typically a few nanoseconds, enabling fast switching speeds in digital circuits. The device also features low power consumption, contributing to energy-efficient designs. The 14-pin SOIC package simplifies automated assembly processes, making it a popular choice for high-volume production. The SN74ACT14DR is commonly used in applications such as clock oscillators, waveform generators, and signal conditioning circuits. Its robust design and reliable performance make it a versatile component in digital electronics.

The SN74ACT14DR logic IC is an essential building block for digital circuits, offering reliable signal inversion and noise immunity. Its hex inverter configuration allows for multiple independent signal inversions within a single package, saving board space and simplifying circuit layout. The Schmitt trigger inputs ensure clean and stable output signals, even in the presence of noise or slow-changing inputs. Whether you're designing a simple logic gate circuit or a complex digital system, the SN74ACT14DR provides the performance and reliability you need.

Ready to enhance your digital designs with a reliable and high-performance hex inverter? The SN74ACT14DR is the perfect choice for signal inversion, pulse shaping, and noise reduction. Its Schmitt trigger inputs guarantee stable operation, while its low power consumption ensures energy efficiency. Don't compromise on signal quality – order your SN74ACT14DR logic IC today and take your projects to the next level. Click here to add the SN74ACT14DR to your cart and start building smarter, more reliable circuits!
